EBMX X-9000 V3 Controller Kit

Looking for increased power?

Look no further than the EBMX X9000 V3 Power Kit, a revolutionary controller upgrade compatible with a variety of electric dirt bikes, including the Surron Light Bee, Surron Ultra Bee, Talaria Sting, Talaria XXX and E Ride Pro.

This plug-and-play kit is engineered to be a direct bolt-in replacement, ensuring a smooth installation process.

Whether you are running a stock battery or an upgraded battery, the EBMX X9000 V3 Controller addition will give your electric dirt bike a significant increase in power.

EBMX X9000 V3 Key Features:

• Next-Level Performance: The EBMX X9000 V3 is built from the ground up for serious riders and racers. With a re-engineered power stage, redesigned logic system, and all-new user interface, it’s the most advanced, rider-focused controller on the market.
• Wide Compatibility: The V3 supports a broad range of electric dirt bikes and motors, including OEM Surron Light Bee, Surron Ultra Bee, Talaria Sting (MX3 & MX4), Talaria XXX, E Ride Pro, EBMX motors, QS138, and other VESC-compatible setups.
• Custom EBMX App: Provides full control over power levels, throttle curves, regen braking, E-Clutch settings, and more—right from your phone. Available on both the App Store and Google Play.
• 6 Fully Customizable Power Modes: Race and street profiles with full adjustability across each mode, so you can fine-tune your setup for different terrain or riding styles.
• High Power Output:

  • 50kW peak output

  • 1000A phase current / 1600A burst

  • 30x 120V Infineon MOSFETs

  • CNC copper busbars and multilayer PCB for superior thermal management

• Next-Gen Control System:

  • EBMX VESC firmware with Field-Oriented Control (FOC)

  • Integrated IMU for Wheel Lift Assist (anti-loop, launch control, stunt modes)

  • Dual Hall Throttle support with 2x ADC inputs for increased safety and throttle redundancy

  • 68 IO support for advanced accessories, lights, sensors, and more

• Advanced Cooling Options:
  Standard heatsink in black, blue, red, gold, or purple. Optional water-cooled heatsink for high-load or race builds
• Waterproof & Built to Last:
  Fully sealed with IP67-rated connectors and CNC-machined aluminum case
  Designed to withstand extreme off-road abuse
• Versatile Display Options:
  Includes the SW102 (EggRider) Display but can also be configured for smartphone pairing via Bluetooth for tuning and ride data
• Firmware & Tune Support:

  • One-touch OTA firmware updates

  • 30+ supported motor tunes preloaded

  • 15+ battery profiles available out of the box

  • Full Load & Go system: select your bike, motor, and battery and ride

With loads of replacement parts available, such as the EBMX X9000 Colored Heatsink (compatible with V2 and V3 controllers only), ECR is the best marketplace to keep your electric dirt bike and EMBC X9000 Controller in tip-top shape.

Fitment

• Surron Light Bee
• Surron Ultra Bee
• Talaria Sting MX3 / MX4 / MX5

• Talaria XXX
• E Ride Pro SS 2.0
• E Ride Pro SS 3.0
• E Ride Pro SR
• ReRode R1
• QS138 Motors
